SAP AppRouters in a Nutshell The Complete Developer Guide You’ve Been Waiting For
Posted on August 14, 2025 by Laeeq Siddique
Introduction:
What is SAP AppRouter?
SAP AppRouter or SAP Application Routers. This is a major building block of SAP’s Business Technology Platform (BTP). These routers are the main entry points for applications that are running in SAP BTP Cloud Foundry – they handle your application authentication, route your requests to your backend services, and secure their communications.
The SAP AppRouter is not as simple as a router; it is more than a router. It’s a Node. js” based middleware (or connect/express) that can help protect your applications by preventing user access to certain pages of an ExpressJS app. It enables developers to specify how requests should be processed, such as forwarding them to a CAP service, an HTML5 app, or even an external API.
You can consider SAP AppRouter as the guard for your SAP cloud-based applications.
Find out more on Wikipedia: App Router
Why SAP AppRouters Matter
SAP AppRouters are essential for providing secure, scalable, and flexible access to cloud applications.
Here are a few critical reasons they’re so important:
- Serve as an aggregator for applications.
- Manage user authentication with SAP’s XSUAA ( Authorization and Trust Management).
- Manage routing to backend services, APIs or front end modules.
- Handle session data, cross-site request forgery protection and CORS on your own.
- Allow for multitenancy in SaaS scenarios.
For folks developing on SAPUI5, CAP, or any cloud native application, AppRouters are very important!
Types of SAP AppRouters
SAP offers two main types of AppRouters:
| Feature | Managed AppRouter | Standalone AppRouter |
| Hosting | SAP | Customer |
| Maintenance | SAP-managed | Self-managed |
| Flexibility | Low | High |
| Customization | Limited | Full control |
| Use Cases | Standard, integrated app | Multi-tenant, custom logic apps |
1. Managed AppRouter
A Managed AppRouter is maintained and hosted by SAP as a service, which is typically packaged with services such as SAP Launchpad, SAP Work Zone, or SAP Fiori. It’s easy to set up and integrates well with SAP’s business services. For most basic scenarios, a managed AppRouter is the preferred option.
2. Standalone AppRouter
For a standalone AppRouter, the developer or organization deploys and manages it. It allows be used to handle complete custom routing, authentication flo,w and middleware as well. It’s perfect for higher-level use cases such as multi-tendency, integrating with an external identity provider, or custom OAuth setup.
How SAP AppRouters Work
The SAP AppRouter process is carried out in a sequence:
- The user interfaces with the application through the AppRouter URL.
- The AppRouter intercepts the request and sees if it needs authentication based on xs-app. json.
- If it requires some form of authentication, the authorization request enters the SAP IDP (Identity Provider).
- Once this token is verified and authenticated, the AppRouter passes the token and navigates the user to the application’s entry file, which is usually index. html).
- All subsequent requests (such as API calls or to services) are forwarded through AppRoute,r and it does the authorization and session check.
AppRouter Configuration Essentials
xs-app.json
This file defines routing rules and authentication settings. A typical configuration might look like:
{
“welcomeFile”: “/index.html”,
“authenticationMethod”: “route”,
“routes”: [
{
“source”: “^/api/(.*)$”,
“destination”: “srv-api”,
“authenticationType”: “xsuaa”,
“csrfProtection”: true
}
]
}
package.json
“scripts”: {
“start”: “node node_modules/@sap/approuter/approuter.js”
}
Destination Configuration
Defined in manifest.yml or default-env.json:
env:
destinations: >
[
{
“name”: “srv-api”,
“url”: “https://api-backend.cfapps.myregion.example.com”,
“forwardAuthToken”: true
}
]
These settings tell the AppRouter where and how to forward requests.
Authentication and XSUAA Integration
AppRouters use XSUAA for OAuth 2.0 authentication and token handling. The user’s login flow, roles, scopes, and sessions are managed seamlessly.
Key benefits of integrating XSUAA:
- OAuth2 flows for secure authentication.
- JSON Web Token (JWT) handling.
- Single Sign-On (SSO) support.
- Scope-based access control.
Developers define security settings using the xs-security.json file.
Example:
{
“xsappname”: “my-approuter”,
“tenant-mode”: “dedicated”,
“scopes”: [
{ “name”: “uaa.user”, “description”: “Standard user scope” }
]
}
When to Use Each AppRouter Type
Use Managed AppRouter When:
- You prefer a ready-to-use, SAP-managed environment.
- The application is single-tenant.
- You’re working with SAP Fiori or SAP Work Zone
Use Standalone AppRouter When:
- You need multi-tenant support.
- Your app requires custom logic or middleware.
- You want to integrate with external identity providers.
- You’re building a SaaS application.
Latest Updates in SAP AppRouter (as of July 2025)
The latest version of @sap/approuter is v20.6.0, released in early July 2025.
New Features:
- mTLS support for enhanced backend security.
- WebSocket compatibility.
- Support for external session storage (e.g., Redis).
- Audit logs, content security policies, and HTTPS options.
Security Patch:
- CVE-2025-24876 (Authentication bypass vulnerability)
Fixed in v16.7.2+. Upgrade to v20.6.0 for full protection.
Check the official NPM release
Conclusion
SAP AppRouters are a core part of the SAP BTP foundation. You use them to manage access, routing, and session. Regardless of whether you use a Managed AppRouter or construct a Standalone version, understanding what makes them tick you will be able to serve secure, scalable, and performant SAP applications.
Understanding SAP AppRouterS also means understanding the bigger SAP spectrum—from authenticating with XSUAA to backend integration via destinations. For businesses and developers that are looking to scale their SAP solutions, AppRouters are not a “nice-to-have,” they’re a “must-have.”
